特點說明
FEATURES
最近電子產品，傾向輕、薄、短、小之要求，故所需電線也趨向細線、
短線及高精度，本機正好能發揮其最大長處。以往被視為很難加工的
50mm 之內的短線，現在並無任何困難，甚至總長度僅有 1mm 時，
兩端亦可同時各剝皮 0.3mm 。同時可分別設定送線、進刀、
退刀再脫皮及脫皮速度，對於隔離線亦可強制脫皮到 99mm ，
排除了以往隔離線不能全剝及傷到心線之困擾。
This machine meet the requirements
of modern electronic features
such as light, short, thin, small and high
precision.
even a difficult processing
wire 1mm to 50mm it can be overcame.
for example, the length is 1mm both ends strip 0.3mm
can be made, even an insulation
wire can be stripped to a
length of 99mm.
𩇕
𩇕
剝皮方式 STRIPPING
METHOD
（短線SHORT WIRE）
𩇕 𩇕
（前後端剝皮）FRONT (REAR) STRIPPING
 𩇕
（前後端半剝）FRONT (REAR) HALF-STRIPPING
（三段剝皮）TRI-SECTION STRIPPING
𩇕 𩇕𩇕𩇕𩇕𩇕𩇕𩇕
𩇕
𩇕
產能表 PCS/HR.
|
機型 MODEL |
XY-220 |
XY-220+T |
XY-220+C1 |
XY-220+T+C1 |
|
20(3X3) |
11860 |
𩇕 |
𩇕 |
𩇕 |
|
50(3X3) |
9080 |
正轉4260 反轉5080 |
𩇕 |
𩇕 |
|
100(3X3) |
8420 |
正轉4090 反轉4860 |
5400 |
3600 |
|
500(3X3) |
5380 |
正轉3210 反轉3660 |
3960 |
3000 |
|
1000(3X3) |
3720 |
正轉2530 反轉2800 |
2880 |
2280 |
𩇕𩇕𩇕𩇕𩇕測試條件 Setting Condition𣂷F1-9 F2-9 F3-9
𩇕
𩇕
規格 SPECIFICATIONS
| 機型𩇕MODEL |
𩇕XY-220 |
| 外觀尺寸𩇕DIMENSION |
𩇕450mmX450mmX360mm |
| 重量𩇕WEIGHT |
𩇕36Kgs(NET) |
| 電源𩇕POWER SUPPLY |
𩇕AC 110V/220V 50/60HZ |
| 消耗電力𩇕POWER CONSUMPTION |
𩇕MIN. 20W~MAX. 220W |
| 切斷長度蕂𠵴𩇕CUTTINGLENGTH |
𩇕0.1~60000mm |
| 剝皮長度𩇕STRIPPING LENGTH |
𩇕0.1~99mm (視線材而定 Depends
on wire material ) 三段剝皮可至999mm |
| 切斷誤差𩇕CUTTING TOLERANCE |
𩇕可修正Adjustable |
| 適用線徑𩇕APPLICABLE SIZE |
𩇕AWG#14~AWG#32 (視線材而定
Depends on wire material) |
|
